JX-T-3 is an array of thin tube carbon nanotube powders with Fe/Co catalytic system, which can be used as a conductive agent for lithium-ion batteries and can be used in high-end 3C digital, power or energy storage batteries. It has good conductivity, improves battery conductivity, rate performance, and cycling performance. The product is easy to disperse, has low viscosity, and has good processing dispersion performance.
Working Mechanism
Has excellent mechanical and electrochemical properties. In the application of batteries, when carbon nanotubes are used as conductive agents, they have a larger aspect ratio, more carbon nanotubes per unit, and denser linear contact with the active material. The highly conductive network effectively connects the active material, reduces impedance, and improves overall conductivity. In addition, carbon nanotubes with larger aspect ratios have a larger specific surface area and require less addition compared to traditional conductive agents.
Technical Specifications
| Technical Specifications of Carbon Nanotube Powder JX-T-3 | ||
| physical property | Unit | Numerical value |
| Average pipe diameter | nm | 7-11 |
| Pipe Chief | μm | ≥30 |
| Purity | % | ≥99.5、≥99.9 |
| Ash content | % | ≤0.5、≤0.1 |
| BET | m2/g | 260-340 |
| Compaction density | g/cm3 | ≥0.01 |
| Moisture content | % | <0.5 |
Product Advantages
1. Array carbon nanotubes have better tendency and good conductivity;
2. Low impurity content and good batch stability;
3. The powder is easy to disperse, with low viscosity and high processing efficiency.
