JX-C01 is a furnace conductive carbon black, which has good dispersion and conductivity after surface treatment, and can be applied to the conductive agent of lithium-ion batteries, suitable for use in consumer or energy storage batteries, and has a high cost performance. It has good performance in battery electrochemical performance and processing and dispersion performance.
Working Mechanism
JX-C01 has polar functional groups on its surface through surface modification treatment, which can be fully dispersed in polar solvents, and evenly coated and filled between the surface and voids of the active material, so that the developed grape branch chain forms a tight conductive network, which provides a rich channel for electron transfer, reduces the impedance, improves the overall conductivity, and improves the conduction efficiency of ions with good liquid retention, which has certain advantages for improving the electrochemical performance of the cell.
Technical Specifications
| Technical Specifications of Conductive Carbon Black JX-C01 | ||
| physical property | Unit | Numerical value |
| BET | m2/g | 60-80 |
| Moisture content | % | ≤0.5 |
| Ash content | % | ≤0.1 |
| Oil absorption value | mL/100g | ≥120 |
| Compaction density | g/cm3 | ≥0.05 |
| Metal impurity content | ppm | Fe≤20 |
Product Advantages
1. Low specific surface area with good electrical conductivity;
2. The impurity content is low, and the particle size distribution is uniform;
3. The powder is easy to disperse, the processing efficiency is high, the viscosity of the slurry is moderate, there are no obvious particles, and the coating surface of the pole piece is smooth.
