N05 is an oligowall carbon nanotube compound slurry with high solid content and moderate viscosity, which is used as a conductive agent for lithium-ion batteries, and can be used in high-nickel ternary systems or silicon-carbon anodes. It has good electrical conductivity, improves battery conductivity, rate performance and cycle performance, good product dispersion, moderate viscosity, and good processing performance.
Working Mechanism
As a conductive agent, the conductive slurry has a larger length and diameter, a larger number of carbon tubes per unit, and a denser point linear contact with the cathode material or the silicon-carbon anode material, and the developed conductive network provides more channels for electron transfer, significantly reducing the impedance, and improving the overall conductivity and rate performance. In addition, carbon nanotubes with large aspect ratios have a larger specific surface area and are added less than conventional carbon nanotubes.
Technical Specifications
| Technical Specifications of Conductive slurry N05 series | ||
| physical property | Unit | Numerical value |
| Solid content | % | 5.38±0.20 |
| Conductive agent content | % | 4.30±0.10 |
| Dispersant content | % | 1.08±0.10 |
| Viscosity | mPa.s | ≤5000 |
| Metal impurity content | ppm | Fe≤20； Ni≤5； Co≤10 |
Product Advantages
1. Array carbon tube, better orientation, with good conductivity;
2. High solid content, low impurity content, moderate viscosity;
3. It is easy to disperse and has high processing efficiency.
